Semi Auto Strapping Machine | Shiv Pack Systems

SEMI AUTO STRAPPING MACHINE PW-311H

Brand Marketing by	Shiv Pack Systems (Taiwan Make)
Input Supply Voltage	220V AC 50–60Hz, Single Phase
Power Consumption	500 Watt
Drive Motor	AC 1/3 HP, 50–60Hz, 1440 RPM, Single Phase
Operating System	PW Integrated PCB with 60 Sec Auto Stop
Used Strap Width Size	6mm, 9mm, 12mm, & 15mm
Sealing Method	Heat Sealing
Strap Speed	2 Seconds per Strap Cycle
Maximum Strap Size	Any Size can you strapping used
Strap Tensioner	15–55 Kg (Inside Adjustment Setting)
Machine Body	Round Corner Edge Design
Machine Weight	108 Kg Approx.
Machine Dimensions (L × W × H)	910 × 580 × 750 mm

Brand Marketing by	Shiv Pack Systems
Input Supply Voltage	220V AC 50–60 Hz
Power Consumption	450 Watt
Driven Motor	AC 1/3 HP, 50–60Hz, 1420 RPM
Strapping Speed	1.5 Sec Cycle per Strap
Used Strap Size	9mm, 12mm, & 15mm
Strap Dispenser	Metal 200mm Strap Core
Machine Body Thickness	2mm MS Auto Powder Coating
M/C Table Top	2mm S.S.
Machine Weight	100 Kg Approx.
Machine Dimensions (L × W × H)	895 × 565 × 735 mm
Tension & Auto Systems	Inside Adjustment & Round Belt

Brand Marketing by	Shiv Pack Systems
Input Supply Voltage	220V AC 50–60 Hz
Power Consumption	450 Watt
Drive Motor	AC 1/3 HP, 50/60Hz, Single Phase
Strap Sealing Speed	1.5 Sec per Strap Cycle
Sealing Method	Heat Sealing
Used Strap Size	9mm, 12mm, & 15mm
Operating Penal Systems	Packway PCB & Round Belt System
Machine Body & S.S Top	1.5 mm Thickness
Machine Dimensions (L × W × H)	890 × 565 × 735 mm
Machine Weight	90 Kg Approx.
